DESCRIPTION
×Get dinner on the table fast with the Whirlpool Induction Range. Its Induction Technology generates heat directly within cookware to heat and boil quickly, and it keeps the cooktop surrounding the elements cool, helping prevent baked-on messes for quick cleaning. It features a large Griddle Zone that allows you to connect two separate heating elements into one so you can cook more food at once. The range makes without the wait thanks to No Preheat Air Fry and Air Cooking Technology modes like Air Baking, Air Roast, and Air Broil. It's also ENERGY STAR® Certified to help save money on your utility bills
FEATURES
×
Features
SPECIFICATIONS
×
Specifications
General
Fuel Type
Electric - Induction
Installation Type
Slide-in
Color
Black Stainless
Manufacturer Color
Black Stainless
Appliance Care
Self-Clean: AquaLift® Self-Cleaning Technology
Cooktop
Burners/Elements
4
Burners/Elements Output
• Right Rear: 2,200 W
• Right Front: 3,700 W
• Left Rear: 3,000 W / 1,400 W
• Left Front: 3,000 W
• Right Front: 3,700 W
• Left Rear: 3,000 W / 1,400 W
• Left Front: 3,000 W
Burner/Element Size
• Right Rear: 5.5 in.
• Right Front: 10.0 in.
• Left Rear: 7.0 in.
• Left Front: 7.0 in.
• Right Front: 10.0 in.
• Left Rear: 7.0 in.
• Left Front: 7.0 in.
Elements
Smoothtop
Oven
Number of Ovens
Single
Programs
• Air Fry
• Auto On
• Bake
• Broil
• Cancel/Off
• Clock
• Control Lock
• Convect Modes
• Cook Time Indicator
• Delay Start
• Frozen Bake
• Keep Warm Setting
• No Preheat - Frozen Lasagna
• No Preheat - Frozen Pizza
• Pro Motor
• Rapid Preheat
• Sabbath Mode
• Stop Time
• Timer
• Auto On
• Bake
• Broil
• Cancel/Off
• Clock
• Control Lock
• Convect Modes
• Cook Time Indicator
• Delay Start
• Frozen Bake
• Keep Warm Setting
• No Preheat - Frozen Lasagna
• No Preheat - Frozen Pizza
• Pro Motor
• Rapid Preheat
• Sabbath Mode
• Stop Time
• Timer
Features
Technologies
• True Convection
• True-Bow Tie
• True-Bow Tie
Air Fry
Yes
Control Lock
Yes
Convection
Yes
Delay Bake/Start
Yes
Digital Temperature Display
Yes
Oven Light
Yes
Self-Cleaning
Yes
Additional Information
• Hot Surface Indicator Light
• Heating Element On Indicator Light
• Automatic Convection Conversion Temperature Adjust
• Convection Element Power: 925 W
• Convection Functions: Air Fry, Bake, Broil
• Broiler Location: Top of Oven
• Broiler Element Power: 4,000 W
• Bake Element Power: 3,600 W
• Automatic Shut Off
• Rack Guide Type: Molded
• Oven Rack Type: 2 Standard
• Oven Light Type: Incandescent
• Oven Light Switch Location: Top of Console
• Oven Control Type: Electronic Touch
• Oven Control Location: Front Control
• Number Of Rack Guides: 7
• Number Of Oven Racks: 2
• Number Of Oven Lights: 1
• Interior Color: Grey
• Hidden Bake Element
• Heating Element On Indicator Light
• Automatic Convection Conversion Temperature Adjust
• Convection Element Power: 925 W
• Convection Functions: Air Fry, Bake, Broil
• Broiler Location: Top of Oven
• Broiler Element Power: 4,000 W
• Bake Element Power: 3,600 W
• Automatic Shut Off
• Rack Guide Type: Molded
• Oven Rack Type: 2 Standard
• Oven Light Type: Incandescent
• Oven Light Switch Location: Top of Console
• Oven Control Type: Electronic Touch
• Oven Control Location: Front Control
• Number Of Rack Guides: 7
• Number Of Oven Racks: 2
• Number Of Oven Lights: 1
• Interior Color: Grey
• Hidden Bake Element
Drawer Features
Storage
Yes
Electrical Information
Information
• Watts: 11,400 W
• Volts: 120 V
• Hz: 60 Hz
• Amps: 40 A
• Volts: 120 V
• Hz: 60 Hz
• Amps: 40 A
Certifications and Approvals
ADA Compliant
Yes
Information
• ENERGY STAR® Certified
• CUL
• UL
• CUL
• UL
Accessories
Included
• W10655448
• W10675026
• W10675028
• W10675026
• W10675028
Optional
W11692811
Dimensions
Class Width
30"
Width
29.88 inch(es) / 75.9 cm
Height
36 inch(es) / 91.44 cm
Depth (Without Handles)
27.88 inch(es) / 70.82 cm
Depth (Including Handles)
28.88 inch(es) / 73.36 cm
Weight
211 lb(s) / 95.71 kg
Additional Dimensions
• Depth With Door Open 90 Degree: 48.5 in.
• Cutout Depth: 24.0 in.
• Cutout Height: 36.0 in.
• Cutout Width: 30.0 in.
• Cutout Depth: 24.0 in.
• Cutout Height: 36.0 in.
• Cutout Width: 30.0 in.
Shipping Dimensions
Width
32 inch(es) / 81.28 cm
Height
43 inch(es) / 109.22 cm
Depth
30.5 inch(es) / 77.47 cm
Weight
228.99 lb(s) / 103.87 kg
Warranty
Warranty
1 Year parts and labor
UPC
UPC#
883049686844
DOCUMENTS
×
